Technical Manual
Motion Detector/Automatic Switch 55/63 [SCN-BWM55/63(T)(06).x2]
State 07/2025 - Version 1.4
4.3.1 Two-button function
The following table shows the available settings:
ETS Text
Dynamic range
[Default value]
Comment
Basic function ■ dimming
■ blinds/shutter
■ switch
Selection of the basic function for the
two-button function.
Table 40: Settings – Two-button function: Basic setting
4.3.1.1 Basic function: Dimming
Two-button function
The dimming function can be used to control Dimming Actuators.
The following table shows the available settings:
ETS Text
Dynamic range
[Default value]
Comment
Button assignment
(left/right)
■ brighter/darker
■ darker/brighter
Setting the button assignment.
Table 41: Settings – Two-button function: Dimming
Two communication objects appear for this button. Firstly, the function for a short button action, the
“Dimming On/Off” switch object, and secondly the function for a long button action, the dimming object
“Dimming relative”. The dimming function is a start-stop dimming function. This means that as soon as the
dimming function is activated, the button sends a “brighter” or “darker” command until the button is
released. After it is released, a “stop” telegram is sent, ending the dimming process.
The two-button function “dimming” can be set either as “brighter/darker” or as “darker/brighter”.
The relationships are shown in the following table:
Function: brighter/darker Function: darker/brighter
Input Button 1 Button 2 Button 1 Button 2
Dimming function Brighter Darker Darker Brighter
Switch function ON OFF OFF ON
Table 42: Two-button function – Dimming
The following table shows the associated communication objects:
No. Name/Object function Length Usage
131 Buttons left/right – Dimming On/Off 1 Bit Switch command for the dimming function.
132 Buttons left/right – Dimming relative 4 Bit Command for relative dimming.
Table 43: Communication objects – Two-button function: Dimming
