MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Telephone: +49 (0) 2263 880 · knx@mdt.de · www.mdt-group.com
42 / 67
Technical Manual
Motion Detector/Automatic Switch 55/63 [SCN-BWM55/63(T)(06).x2]
State 07/2025 - Version 1.4
4.3 Buttons
SCN-BWM55T(06).x2
SCN-BWM63T.02
If the device is an SCN-BWMxxT(06).x2 model, it will have two buttons that can be used to control various
functions. These buttons allow you to perform functions such as switching, dimming, blind control or
sending values, either as a single-button function or as a two-button function. In addition, internal
functions such as switching to manual mode or activating lock or forced control modes can be operated.
The following table shows the available settings:
ETS Text
Dynamic range
[Default value]
Comment
Time for long keypress 0,1 s – 10 s
(0,6 s)
Setting for when a long keypress is
recognised.
Function of buttons ■ not active
■ Two-button function
■ Single-button function
■ internal function / manual mode
(light channel 1)
Setting the functions for the button
pair.
Table 39: Settings – Buttons: Basic setting
Time for long keypress
Thisparametercanbeusedtoassignaxedtimevaluetothebutton,fromwhichpointitrecognisesa
keypress as “long”. This parameter is important for objects that have functions for both, a short and a long
keypress.
Function of buttons
The button settings are used to specify whether the buttons are to be assigned as single or two buttons, or
whether pre-assigned internal functions are to be executed with the buttons:
■ not active: Ifthebuttonsaredeactivated,theycannolongerbecongured.
■ Two-button function: If you press one of the buttons, the corresponding function is activated. If, for
example, “Switching” is selected, it is possible to specify that one button sends an “ON” command and
the other consequently an “OFF” command.
■ Single-button function:Parametersforbothbuttonsappear,whichcanbefreelycongured
independently of each other.
■ internal function / manual mode (light channel 1):Thebuttonshavepredenedinternalfunctions.
