MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Telephone: +49 (0) 2263 880 · knx@mdt.de · www.mdt-group.com
24 / 67
Technical Manual
Motion Detector/Automatic Switch 55/63 [SCN-BWM55/63(T)(06).x2]
State 07/2025 - Version 1.4
4.2.1.4.1 Output object: Switch
Light channel
HVAC channel
The following table shows the available settings:
ETS Text
Dynamic range
[Default value]
Comment
Only for Light channel 1/2
Output objects for Day/
Night
■ one common object
■ separate objects
Setting for whether to send via one
or two objects.
Only for HVAC channel
Object value for “Day”
when ON
■ Value “0”
■ Value “1”
Setting the value to be sent for the
corresponding operation.
Object value for “Day”
when OFF
■ Value “0”
■ Value “1”
Object value for “Night”
when ON
■ Value “0”
■ Value “1”
Object value for “Night”
when OFF
■ Value “0”
■ Value “1”
Table 21: Settings – Output object: Switch
Light channels
If “one common object” is selected, the output sends to one object, regardless of whether it is in Day or
Night mode. The sent object value can not be inverted.
With “separate objects”, 2 switch objects are displayed - one for Day mode and one for Night mode. For
example, the main light can be switched on in Day mode and a small night light in Night mode.
HVAC channel
Thereisonlyoneoutputhere.Theobjectvaluesforthecorrespondingoperationaredeneddirectly.
The following table shows the associated communication objects:
No. Name/Object function Length Usage
0 Light channel 1 - Output 1 – Switch 1 Bit Switching function for Day and Night mode.
0 Light channel 1 - Output 1 (Day) – Switch 1 Bit Switching function for Day mode.
1 Light channel 1 - Output (Night) – Switch 1 Bit Switching function for Night mode.
2 Light channel 1 - Output 2 (Additional) –
Switch
1 Bit Switching function with an additional
object.
+15 Light channel 2 ...
60 HVAC - Output – Switch 1 Bit Switching function of the HVAC channel.
Table 22: Communication objects – Output object: Switch
