Technical Manual – Push Button Smart 55/63
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Phone: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
83
83
The setting "Send measured value on change" can be used to set the change on which the sensor
sends its current relative humidity measured value. If the setting is "do not send", the sensor does
not send a value, regardless of the size of the change.
The setting "Send measurement value cyclically" can be used to set the intervals at which the sensor
sends its current relative humidity measurement value. The cyclical sending function can be activated
or deactivated independently of the setting "Send measured value on change". Measured values are
also sent if the sensor has not detected a change. If both parameters are deactivated, no value is
ever sent.
In addition, a correction value can be parameterised for the internal sensor under the setting
"Calibration value for internal sensor". This correction value serves to increase/decrease the actual
measured value. The adjustment range is from -20 to 20 %, i.e. the measured value can be lowered
by -20 % and raised to a maximum of 20 %. For example, if a value of 10 is set, the measured
humidity value is increased by 10 %. The humidity sensor sends the corrected humidity value when
this function is activated.
Important: After initial installation/programming, the measured values are stable after approx. 30
minutes.
An external sensor can be activated or deactivated via the weighting "Sensor internal/external". If
the weighting is set to 100% internal, no external sensor is activated and no communication objects
appear for the external sensor. With any other weighting, an external sensor is activated and the
associated communication objects are also displayed. The "External humidity sensor" communication
object receives the relative humidity currently measured by the sensor. The "mixed" relative
humidity is shown in the display and this humidity value is transmitted via object 84.
Example:
Weighting: 50% internal / 50% external, internal sensor 40%, external relative humidity 20%.
=> transmitted relative humidity 30 %.
The external humidity sensor is monitored with a time of 30 min. In case of an error, only the
internal sensor is used!
If the function "Messages" is activated, two messages can be parameterised. One is the message
function for the lower response value, the "minimum message value", and the other the upper
response value, the "maximum message value".
The two message functions each have a separate communication object.
Principle:
If the maximum value is exceeded, a "1" is transmitted. If the value falls below it, a "0" is transmitted.
If the value falls below the minimum value, a "1" is transmitted. If it is exceeded, a "0" is transmitted.
The following table shows the available communication objects:
Number
Name
Length
Usage
84
Relative air humidity –
Send measured value
2 Byte
Sends the currently measured relative
humidity
85
Relative air humidity –
External humidity sensor
2 Byte
Receives the humidity of the external
sensor
86
Relative air humidity –
Max. value exceeded
1 Bit
Sends a message if the upper message
value is exceeded
87
Relative air humidity –
Min. value fallen below
1 Bit
Sends a message when the value falls
below the lower message value
Table 79: Communication objects – Relative air humidity
