Technical Manual – Push Button Smart 55/63
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Phone: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
50
50
The following table shows the available settings:
ETS-Text
Dynamic range
[Default value]
Comment
Action short/long
keypress
▪ Switch
▪ Switch Off
▪ Switch On
▪ Toggle
▪ Send values
▪ Not active
Setting the function for the
short/long key.
"Switch On/Off" only for single-
button function.
"Switch" only with two-button
function
Datapoint type
▪ 2Bit DPT 2.001 Switch Control
▪ 1Byte DPT 5.001 Percent (0…100%)
▪ 1Byte DPT 5.005
Decimal factor (0…255)
▪ 1Byte DPT 17.001 Scene number
▪ 2Byte DPT 7.600
Color Temperature (Kelvin)
▪ 2Byte DPT 9.001 Temperature (°C)
▪ 2Byte DPT 9.004 Brightness (Lux)
▪ 3Byte DPT 232.600
RGB Value 3x(0…255)
Setting the datapoint type for
the value to be sent
Setting only available if "Action
short/long keypress" is set to
"Send values".
Value button 1-4
any value according to set datapoint type
Only for two-button function!
Setting the respective value on
operation
Value
any value according to set datapoint type
Only for single-button function!
Setting the respective value on
operation
Behavior at long
keypress
▪ Do not send “short”
▪ Send “short”
Setting whether the value for
the short button is also
transmitted when the long
button is pressed
Sending condition for
long keypress
▪ Upper/left and lower/right
buttons may send
▪ Only upper/left button may send
▪ Only lower/right button may
send
Only for two-button function!
Setting the sending condition for
the long button.
Value upper/lower or left/right
key depends on the key
alignment “horizontal/vertical”
Time for long keypress
Basic setting
0,1 s – 30,0 s
Setting from when a long
keypress is detected
Display of function
short/long
▪ Display action of short button
▪ Display action of long button
Setting which button should be
shown on the display as the
status
Table 39: Settings – Switch/send values short/long (with 2 objects)
Functional principle:
With the two-button function you can send different values for the two buttons (for the short and
long buttons). With the single-button function, only one value can be sent for both the short and the
long button. You can define the type of data point separately for the short and long keys.
