Technical Manual – Push Button Smart 55/63
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Phone: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
40
40
The following table shows the available communication objects:
Number
Name
Length
Usage
0
Push Button 1:
Push Buttons 1/2: –
Switch control, Percent value…..
Switching function of the button(s).
DPT depending on the parameter setting
2
Push Button 1 (2.Object):
Push Buttons 1/2 (2.Object): –
Switch control, Percent value…..
Switching function of the button(s) for
the 2
nd
object.
DPT depending on the parameter setting
2
Push button 1 group long:
Push buttons 1/2 group long: –
Switch control, Percent value…..
Switching function of the long button.
DPT depending on the parameter setting
3
Push Button 1:
Push Buttons 1/2: – Status for display
Receive the status for the display. DPT
depending on the parameter setting.
RGB 3 bytes cannot be displayed.
4
Push button 1 group extra long:
Push buttons 1/2 group extra long: –
Switch control, Percent value…..
Switching function of the extra long
button.
DPT depending on the parameter setting
Table 28: Communication objects – Send values - Subfunction: Send values
4.6.5.2 Subfunction: Toggle Values/Scenes (up to 4 Values)
Single-Button function
Two-Button function
With the function: Send values - Toggle values/scenes you can switch between 4 different values of a
datapoint type.
The following figure shows the available settings for the Two-button function:
Figure 20: Settings – Send Values - Subfunction: Send Values/Scenes (up to 4 values)
