Technical Manual – Push Button Smart 55/63
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Phone: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
39
39
Special function: Innovative Group control
Group long keypress
▪ not active
▪ active
Activating a function with a long
keystroke
Group long sends
▪ Value for upper/left and
lower/right button
▪ Only value for upper/left button
▪ Only value for lower/right button
Only with two-button function!
Setting which key reacts to the
long keystroke.
Value upper/lower or left/right
button depends on the key
alignment horizontal or vertical
Group extral long
keypress
▪ not active
▪ active
Activating a function with an
extra long keystroke
Group extral long
sends
▪ Value for upper/left and
lower/right button
▪ Only value for upper/left button
▪ Only value for lower/right button
Only with two-button function!
Setting which key reacts to the
extra long keystroke.
Value upper/lower or left/right
button depends on the key
alignment horizontal or vertical
Time for long keypress
Basic setting
0,1 s – 30 s
Setting of an individual time from
when a long keystroke is
detected
Time for extral long
keypress
0,1 s – 30 s
[2,0 s]
Setting of an individual time from
when an extra long keystroke is
detected
Special function: Additional object
Datapoint type
(2. object)
▪ 1Bit DPT 1.001 Switch
▪ 2Bit DPT 2.001 Switch Control
▪ 1Byte DPT 5.001 Percent (0…100%)
▪ 1Byte DPT 5.005
Decimal factor (0…255)
▪ 1Byte DPT 17.001 Scene number
▪ 2Byte DPT 7.600
Color Temperature (Kelvin)
▪ 2Byte DPT 9.001 Temperature (°C)
▪ 2Byte DPT 9.004 Brightness (Lux)
▪ 3Byte DPT 232.600
RGB Value 3x(0…255)
Only available if "additional
object" is selected.
Setting the datapoint type to be
sent for the additional object
Value button 1–4
any value according to set datapoint type
Only with two-button function!
Setting the action for the
additional object
Value
any value according to set datapoint type
Only for single button function!
Setting the action for the
additional object
Table 27: Settings – Send values - Subfunction: Send values
For details of the innovative group control, see 4.6.4 Switch.
If you select "Additional object", a further communication object appears. Here, it is possible to send
different values to two separate objects when a key is pressed. For example, the first object can be
used to send a dimming value in % to a dimming actuator and simultaneously send an RGB value to
an LED controller.
