Technical Manual – Push Button Smart 55/63
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Phone: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
32
32
4.6.4 Switch
Single-Button function
Two-Button function
The following figure shows the available settings for the button function "Switch", here an example
of the two-button function:
Figure 13: General Settings – Switch
The following parameters are identical for all subfunctions of the "Switch" button function:
ETS-Text
Dynamic range
[Default value]
Comment
Button assignment (1/2)
▪ On/Off
▪ Off/On
Only for two-button function. Defines
the sending behaviour of the buttons
Subfunction
▪ Switch
▪ Toggle
▪ Send status
Only for single-button function. Defines
the sub-function and displays further
parameters if necessary
Value pushed button
▪ Off
▪ On
Only for single-button function,
„switch“ and „send status“. Defines the
sending behaviour of the button
Value released button
▪ Off
▪ On
Only for single-button function, „send
status“. Defines the sending behaviour
of the button
Delay released button
▪ Not active
▪ Active
Only for single button function, „send
status“. Defines a delay of the telegram
to be sent
Innovative group control
Group long keypress
▪ ON and OFF
▪ Only ON
▪ Only OFF
Only shown when a long keypress is
active!
Defines the sending behaviour when a
long keypress is active.
For single button functions, the
sending behaviour is defined according
to the subfunction.
