Technical Manual – Push Button Smart 55/63
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Phone: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
24
24
4.4 Status/Messages
4.4.1 State values 1-3
Here the status values, which are available for selection in the info display as state elements, can be
defined.
The following picture shows the possible settings:
Figure 8: Settings – State Values 1 - 3
The following table shows the possible settings:
ETS-Text
Dynamic range
[Default value]
Comment
State value 1 – 3
▪ Not active
▪ ON/Off (DPT 1.001)
▪ Percent 0…100% (DPT 5.001)
▪ Value 0…255 (DPT 5.005)
▪ Current [mA] (DPT 7.012)
▪ Brightness [Lux] (DPT 7.013)
▪ Temperature [°C] (DPT 9.001)
▪ Brightness [Lux] (DPT 9.004)
▪ Wind speed [m/s] (DPT 9.005)
▪ Humidity [%] (DPT 9.007)
▪ Air quality [ppm] (DPT 9.008)
▪ Current [mA] (DPT 9.021)
Setting the DPT to be displayed
as status value
