Technical Manual – Push Button Smart 55/63
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Phone: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
57
57
2 Byte shift of basis comfort setpoint
With the "2 byte shift of the basic comfort setpoint" the push-button sends a new basic comfort
setpoint to the controller to be activated. It evaluates the object "Status basis comfort setpoint" and
sends the new setpoint +/- the set step width to the controller to be actuated.
The range for the setpoint adjustment can be limited via the limits of the setpoint adjustment to be
set.
The following table shows the available communication objects:
Number
Name
Length
Usage
0
Push buttons 1/2 –
Basis comfort setpoint
2 Byte
Sends the Setpoint shift
1
Push buttons 1/2 –
Status current
temperature
2 Byte
Receiving an external temperature for the
display of the current temperature - is only
displayed if the parameter "Use internal
temperature value" is set to "not active"
2
Push buttons 1/2 –
Status current setpoint
2 Byte
Receiving the current setpoint temperature of
the temperature controller; to display the
status
3
Push buttons 1/2 –
Status basis comfort
setpoint
2 Byte
Receives the current status of basis comfort
setpoint from the controller.
Table 47: Communication objects – 2 Byte shift of comfort setpoint value
Presentation:
Two-Button function
The temperature shift is represented by the temperature symbol. The representation is fixed to this
symbol.
Figure 28: Presentation – Temperature shift
