The temperature can be shifted in 4 different ways:
1 Bit temperature shift
With the 1-bit temperature shift the Push Button Smart 55/63 merely transmits the command 1 for a
shift of the setpoint upwards and a 0 for a shift of the setpoint downwards.
The following table shows the available communication objects:
Number
Name
Length
Usage
0
Push buttons 1/2 – Setpoint
shift
1 Bit
Sends the Setpoint shift
1
Push buttons 1/2 –
Status actual temperature
2 Byte
Receiving an external temperature for the display
of the current temperature - is only displayed if
the parameter "Use internal temperature value"
is set to "not active"
2
Push buttons 1/2 –
Status actual setpoint
2 Byte
Receiving the current setpoint temperature of the
temperature controller; to display the status
Table 44: Communication objects – Temperature shift via 1 Bit
1 Byte temperature shift
With the 1-byte temperature shifting, the Push Button Smart 55/63 sends a 1-byte value which is
multiplied by the step width set in the controller. In order for the display and the current setpoint
value to be synchronous, the step width and the limits of the setpoint shift have to be specified in the
Push Button Smart 55/63.
The following table shows the available communication objects:
Number
Name
Length
Usage
0
Push buttons 1/2 –
Setpoint shift
1 Byte
Sends the Setpoint shift
1
Push buttons 1/2 –
Status current temperature
2 Byte
Receiving an external temperature for the display
of the current temperature - is only displayed if
the parameter "Use internal temperature value"
is set to "not active"
2
Push buttons 1/2 –
Status current setpoint
2 Byte
Receiving the current setpoint temperature of
the temperature controller; to display the status
3
Push buttons 1/2 –
Status setpoint shift
2 Byte
Receives the current status of setpoint shift from
the controller.
Table 45: Communication objects – Temperature shift via 1 Byte
