Technical Manual – Push Button Smart 55/63
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Phone: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
53
53
4.6.7 Temperature Shift
Two-Button function
Function only available with Push Button Smart 55/63 with temperature sensor.
The temperature shift can be used to shift the setpoint value of the heating control.
The following picture shows the available settings (here shifting over 1 bit):
Figure 27: Settings – Temperature shift
The following table shows the available settings:
ETS-Text
Dynamic range
[Default value]
Comment
Temperature shift
▪ 1 Bit temperature shift
▪ 1 Byte temperature shift
▪ 2 Byte temperature shift
▪ 2 Byte shift of basis
comfort setpoint value
Setting how the temperature is to be
shifted
Key assignment (1/2)
▪ Shift temperature
up/down
▪ Shift temperature
down/up
Assignment of which key is used to
shift up and which key is used to
shift down
Use internal temperature
▪ not active
▪ active
Setting whether the internal
temperature measurement value is
to be used to display the actual value
Step width
0,1 … 1 K
[0,5 K]
Set the step width between two
send commands.
Not visible when shifting over 1 bit
Lower limit
-10 … 10 K
[-5 K]
Setting of the lower limit value for
the setpoint shift.
Only for shifting over 1Byte/2Byte
Upper limit
-10 … 10 K
[5 K]
Setting of the upper limit value for
the setpoint shift.
Only for shifting over 1Byte/2Byte
