Technical Manual – Push Button Smart 55/63
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Phone: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
52
52
If the function has been parameterized as "Send values", the following settings are possible.
The presentation of the function "send values" depends on the selected datapoint type. Depending
on the selected datapoint type, 1-4 different symbols and their color can be selected.
The following table provides an overview of the settings for the various datapoint types:
Datapoint type
Adjustable symbols
Comment
1 Bit Switch, DPT 1.001
2 Symbols, for ON and OFF
2 Bit Switch control, DPT 2.001
4 symbols can be set: 1 symbol
for each possible state
1 Byte Percent, DPT 5.001
Three icons can be set for the
ranges 0%, 1% - 90% and > 90%.
Therefore the button evaluates
the information of the "Status
for display" object
Special presentation possible!
Additionally it is possible to
display the status value below
the symbol.
1 Byte Decimal factor, DPT
5.005
3 symbols can be set for the
ranges 0, 1-229 and 230-255.
Therefore, the button evaluates
the information of the "Status
for display" object
Special presentation possible!
Additionally it is possible to
display the status value below
the symbol.
1 Byte Scene Number, DPT
17.001
1 fixed symbol can be set
2 Byte Color temperature
(Kelvin), DPT 7.600
1 fixed symbol can be set
2 Byte Temperature, DPT 9.001
1 fixed symbol can be set
Special presentation possible!
2 Byte Brightness, DPT 9.004
1 fixed symbol can be set
3 Byte RGB Wert, DPT 232.600
1 fixed symbol can be set
Table 41: Presentation (Symbols) – Send values
Special presentation:
For certain data point types, a special presentation (see table above) is possible
The following presentations are possible:
ETS-Text
Dynamic range
[Default value]
Comment
Special display
(DPT 5.001, DPT 5.005)
▪ bar symbol
▪ bar symbol with fan
▪ value as text (0-100%)
▪ value as text (0-255)
At the settings “bar symbol”
and “bar symbol with fan”, the
corresponding symbol is
displayed and the bar is filled
according to the current status.
With the settings "value as
text" the text is displayed large
on the display.
Special display (DPT 9.001)
▪ value as symbol + “°C”
▪ value as symbol without
unit
▪ value as symbol + “K”
With the settings "value as
symbol" the text is displayed
large on the display.
Table 42: Special presentation – Send values
