Technical Manual – Push Button Smart 55/63
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Phone: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
41
41
The following table shows the available settings:
ETS-Text
Dynamic range
[Default value]
Comment
Key assignment
(1/2)/(3/4)
▪ next / previous
▪ previous / next
Only for two-button function!
Setting in which direction to
switch when the keys are
pressed
Number of values
▪ 2
▪ 3
▪ 4
Setting between how many
values to be switched
Datapoint type
▪ 2Bit DPT 2.001 Switch Control
▪ 1Byte DPT 5.001 Percent (0…100%)
▪ 1Byte DPT 5.005
Decimal factor (0…255)
▪ 1Byte DPT 17.001 Scene number
▪ 2Byte DPT 7.600
Color Temperature (Kelvin)
▪ 2Byte DPT 9.001 Temperature (°C)
▪ 2Byte DPT 9.004 Brightness (Lux)
▪ 3Byte DPT 232.600
RGB Value 3x(0…255)
Setting the type of data point
to be sent
1.-4. Toggle value
any value according to set datapoint type
Setting the respective value
for the toggle value
Time delay between the
toggle values
no delay
1 s – 10 s
Setting a delay between
sending the toggle values
Long keypress
▪ not active
▪ active
Activating a function with a
long keystroke
Button 1-4:
Action at long
keypress
• 1.-4. Toggle value
• 4. Toggle value if last 1. Toggle
value, otherwise 1.
.
Toggle value
• Send 0
• “Off” to second object
• “On” to second object
Only for two-button function!
Setting the action with long
keystroke
Action with a long
keypress
• 1.-4. Toggle value
• 4. Toggle value if last 1. Toggle
value, otherwise 1.
.
Toggle value
• Send 0
• “Off” to second object
• “On” to second object
Only for single-button
function!
Setting the action with long
keystroke
Time for long keypress
Basic setting
0,1 s – 30 s
Setting of a time from when a
long keystroke is detected
Switching type
• Limit stop (after the last value,
this is repeated)
• Overrun (after the last value, the
first value is sent again)
Only for two-button function!
Setting what should happen
when the last switching value
is reached
Table 29: Settings – Send Values - Subfunction: Send Values/Scenes (up to 4 values)
