Technical Manual – Push Button Smart 55/63
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Phone: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
33
33
Group extra long keypress
▪ ON and OFF
▪ Only ON
▪ Only OFF
Only shown when a long and extra long
keypress is active!
Defines the sending behaviour when a
extra long keypress is active.
For single button functions, the
sending behaviour is defined according
to the subfunction.
Time for long keypress
Basic setting
0,1 s – 30,0 s
Setting from when a long keypress is
detected
Time for extra long
keypress
0,1 s – 30,0 s
[2,0 s]
Setting from when an extra long
keypress is detected
Table 22: General Settings – Switch
Innovative group control
With the innovative group control, it is possible to send to up to three different group addresses by
pressing and holding a key. The time for the long and extra long keypress is set individually. With the
two-button function, you can also set the sending behaviour for the long and extra long group.
All groups are always sent one after the other.
Example:
Time long key press: 2 s
Time extra long key press: 4 s
If the key is now pressed for at least 4 seconds, the first value is transmitted immediately, after 2
seconds the value for "group long" and after 4 seconds the value for "group extra long".
4.6.4.1 Switching with the two-button function
Two-Button function
With the two-button function, the respective value (on/off) can be assigned to the two buttons
(depending on the horizontal/vertical key setting). This means that the upper/left or lower/right key
sends the set, fixed value.
The following figure shows the available settings for the two-button switching function:
Figure 14: Settings – Two-button function: Switch
Key assignment On/Off: Key 1 sends the value ON and Key 2 sends the value OFF.
Key assignment Off/On: Key 1 sends the value OFF and Key 2 sends the value ON.
For details of the innovative group control, see 4.6.4 Switch.
