MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Telephone: +49 (0) 2263 880 · knx@mdt.de · www.mdt.de
33 / 63
Technical Manual
Push Button Lite 55/63/Basic [BE-TALxxxx.x1]
State 09/2024 - Version 1.4
ETS Text
Dynamic range
[Default value]
Comment
Action on long
keypress
■ 1.-4. Toggle value
■ 4. Toggle value if 1. Toggle value was
previously set, otherwise 1. Toggle value
■ send “0”
■ “OFF” to second object
■ “ON” to second object
■ save scene
[1. Toggle value]
Setting the action with long
keypress.
Number of possible switching
values according to the selection
“Number of values”.
Only with single-button function
and when “Long keypress“ is
active.
Time for long
keypress
basic setting
0,1 s - 30,0 s
Setting of a time from when a long
keystroke is detected.
Switching type ■ limit stop (after the last value, this is
repeated)
■ overrun (after the last value, the rst
value is sent again)
Setting what should happen if the
last toggle value is reached.
Only with two-button function.
Table 17: Settings – Send values – Subfunction: Toggle values/scenes
Functional principle
This function can send up to 4 different values when a button is pressed shortly. The values are toggled
one after the other. Depending on the set parameters, for example, when the button is pressed, the 2nd
toggle value is sent if the 1st toggle value was previously sent and the 3rd toggle value if the 2nd toggle
value was previously sent.
Delay between switchovers
With this setting, the sending of the telegram is delayed by the set time after the button is pressed. If you
press the button again during the delay time, the next toggle value is activated immediately and the delay
time is restarted. If, for example, you want to go directly from the 1st toggle value to the 3rd toggle value
without activating the second one - with a delay time of 2 seconds - press the key twice within 2 seconds.
Long keypress
The parameter “Long keypress” can be used to transmit a xed value for a long keypress in addition to the
changeover by a short keypress.
