Push Button Lite 55/63/Basic [BE-TALxxxx.x1]
State 09/2024 - Version 1.4
4.3.3.2 Subfunction: Toggle values/scenes
Single-button function
Two-button function
This function can be used to switch between up to 4 different values of a datapoint type.
The following table shows the available settings:
ETS Text
Dynamic range
[Default value]
Comment
Button assignment
(1/2) (3/4)
■ next/previous
■ previous/next
Setting in which direction to toggle
when the upper/left or lower/right
button is pressed.
Only with two-button function.
Number of values ■ 2
■ 3
■ 4
Setting between how many values
are to be toggled.
Datapoint type ■ 2 Bit DPT 2.001 Forcible control
■ 1 Byte DPT 5.001 Percent (0…100%)
■ 1 Byte DPT 5.005 Decimal factor (0…255)
■ 1 Byte DPT 17.001 Scene number
■ 2 Byte DPT 7.600 Colour temperature (K)
■ 2 Byte DPT 9.001 Temperature (°C)
■ 2 Byte DPT 9.004 Brightness (Lux)
■ 3 Byte DPT 232.600 RGB value
Setting the type of datapoint to be
sent.
Colour control ■ RGB
■ HSV
Selection of colour system.
Only for “RGB value“.
1. - 4. Toggle value
1. - 4. Toggle
Scene number
any value
according to set datapoint type
Setting the value to be sent.
Delay between
switchovers
no delay
1 s - 10 s
Setting a delay between sending
the toggle values.
Long keypress ■ not active
■ active
Activating a function with a long
keystroke.
Button 1/2 (3/4):
Action on long
keypress
■ 1.-4. Toggle value
■ 4. Toggle value if 1. Toggle value was
previously set, otherwise 1. Toggle value
■ send “0”
■ “OFF” to second object
■ “ON” to second object
■ save scene
[1. Toggle value]
Setting the action with long
keystroke.
Number of possible switching
values according to the selection
“Number of values”.
Only with two-button function
and when “long keypress“ is
active.
