56 / 63
Technical Manual
Glass Push Button II Lite [BE-GTLxxx.x1]
State 09/2024 - Version 1.4
Sending condition
If a logic operation is fullled, the corresponding value is sent.
If the object type is “Switch”, the “Sending conditions” are as follows:
■ not automatic: The output value is not sent automatically.
■ on incoming telegram: The output value is sent with every input telegram, regardless of whether the
output value has changed or not.
■ on change of output: The output value is only sent if the output value has changed.
■ on change of output (send only “0”): The output value is only sent if the output value changes and the
result of the logic operation is “0”.
■ on change of output (send only “1”): The output value is only sent if the output value changes and the
result of the logic operation is “1”.
Invert output
With the “switch” object type, the output can be inverted, thus turning a “0” into a “1” and a “1” into a “0”.
The following table shows the associated communication objects:
No. Name/Object function Length Usage
52 Logic 1 – Output:
Switch, Value, Scene
Output of the logic operation.
DPT according to parameter setting.
+3 next Logic – Output
Table 49: Communication objects – Logic: Output objects
4.5.3 Submenu – Logic 1 - 4
A submenu is displayed for each activated logic. The following table shows all available settings:
ETS Text
Dynamic range
[Default value]
Comment
Logic object A/B
(external)
■ not active
■ normally active,
with preallocation “0”
■ inverted active,
with preallocation “0”
■ normally active,
with preallocation “1”
■ inverted active,
with preallocation “1”
Activation of external logic objects. The
preallocation denes the value of the
external logic object after a bus power
return, up to a value being received.
Internal Input 1/2 ■ not active
■ button 1 - 4
Activation of the internal logic objects.
The number of buttons depends on the
device type.
