Glass Push Button II Lite [BE-GTLxxx.x1]
State 09/2024 - Version 1.4
ETS Text
Dynamic range
[Default value]
Comment
Setting for “Object type 1” → “Switch“
Sending condition ■ not automatic
■ on incoming telegram
■ on change of output
■ on change of output (send only “0”)
■ on change of output (send only “1”)
Setting the sending condition for
the output object.
Invert output ■ no
■ yes
Setting for the polarity with which
the output object is sent.
Setting for “Object type 1” → “Scene number“
Scene number 1 - 64
[2]
Set the scene to be sent when the
logic condition is true.
Setting for “Object type 1” → “Decimal factor“
1 Byte Value 0 ... 255
[0]
Set the value to be sent when the
logic condition is true.
Setting for “Object type 1” → “Forcible control“
Forcible control ■ 00 - no priority, OFF
■ 01 - no priority, ON
■ 10 - priority OFF
■ 11 - priority ON
Set the value to be sent when the
logic condition is true.
The settings for logic 2 - 4 correspond to those of logic 1
Table 48: Settings – Logic 1 - 4
Function/Object description
There are 2 text elds available:
Function/Object description
Light - Terrace
Additional text
Lightning dimmed
Figure 7: Text elds – Function/Object description and Additional text
Texts with up to 40 characters can be stored for both elds. The text entered in “Function/Object
description” appears both in the menu behind the corresponding logic and with the communication
objects of the logic:
– Logic basic settings
Logic 1: Light - Terrace
...
|52 Logic 1: Light - Terrace Output: Value
Figure 8: Function/Object description
The “Additional text” is used only as additional information about the logic and is not displayed anywhere
else.
