Technical Manual
Glass Push Button II Lite [BE-GTLxxx.x1]
State 09/2024 - Version 1.4
Cleaning function
This function locks the function against further operation or sending a telegram for 10 seconds. If other
buttons are pressed within these 10 seconds, e.g. when cleaning the button, the device remains locked.
The cleaning function is indicated by white flashing of every status LED.
Slap function
The slap function can be used as an additional button. This allows a specic command to be sent by simply
“slapping” the button, e.g. to switch the light on or off when entering a room. The slap function is executed
when 3 or more buttons are pressed at the same time. The value to be sent can be set using the “slap
function” parameter. An active slap function can be signalled by a congurable colour via the status LEDs.
The status LEDs flash briefly in the congured colour.
If the cleaning function is deactivated, values can be sent using the slap function with both, a long and a
short keypress.
The following table shows the associated communication objects:
No. Name/Object function Length Usage
40 Slap-button short –
Switch OFF, Switch ON, ...
Denes the sending behaviour of the function.
DPT depending on the parameter setting.
41 Slap-button short –
Status for toggle
1 Bit Receiving the current status of the
actuator to be controlled.
Only with “toggle” function.
42 Slap-button long –
Switch OFF, Switch ON, ...
Denes the sending behaviour of the function.
DPT depending on the parameter setting.
43 Slap-button long –
Status for toggle
1 Bit Receiving the current status of the
actuator to be controlled.
Only with “toggle” function.
49 Slap-button – Lock object 1 Bit Locking object for the slap-function.
Table 38: Communication objects – Slap/Cleaning function
