MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Telephone: +49 (0) 2263 880 · knx@mdt.de · www.mdt.de
46 / 63
Technical Manual
Glass Push Button II Lite [BE-GTLxxx.x1]
State 09/2024 - Version 1.4
4.3.8 Slap/Cleaning function
The following table shows the available settings:
ETS Text
Dynamic range
[Default value]
Comment
Cleaning function ■ cleaning not active, slap active
■ cleaning = long button,
slap = short button
■ cleaning = short button, slap = long
button
Activation of the Cleaning-/Slap
function and setting if activation via
short or long keypress.
Slap function for
short keypress
■ switch OFF
■ switch ON
■ toggle
■ send values
■ not active
Setting the value to be sent for the
“short keypress” slap function.
Datapoint type ■ 2 Bit DPT 2.001 Forcible control
■ 1Byte DPT 5.001 Percent (0…100%)
■ 1Byte DPT 5.005 Decimal factor (0…255)
■ 1Byte DPT 17.001 Scene number
■ 2Byte DPT 7.600 Colour temperature (K)
■ 2Byte DPT 9.001 Temperature (°C)
■ 2Byte DPT 9.004 Brightness (Lux)
■ 3Byte DPT 232.600 RGB value
Setting the datapoint type for the
value to be sent.
Only if “Slap function for short
keypress“ → “send values“.
Colour control ■ RGB
■ HSV
Selection of colour system.
Only for “RGB value“.
Value
Scene number
RGB value
HSV value
any value
according to set datapoint type
Setting the value/scene number to
be sent.
The settings for the “Slap function for long keypress” behave in a similar way.
Time for long
keypress
basic setting
0,1 s - 30,0 s
Setting of a time from when a long
keystroke is detected.
Display behaviour of
LEDs
off, red, green, yellow, [blue], pink, cyan,
white, Slap function not signalled via LEDs
LED display behaviour if the slap
function is active.
Lock object ■ not active
■ active
Activation of the lock object for the
slap function.
Table 37: Settings – Slap/Cleaning function
Note: The Slap/Cleaning function is activated by pressing 3 or more buttons at the same time.
