Technical Manual
Glass Push-button II Smart & Push-button Smart 86 [Series .02]
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Germany
Phone: +49-2263-880 • knx@mdt.de • www.mdt.de
83
83
With colour temperature (Tunable White), the light temperature can be controlled. A 4-bit dimming
command is available for the control. This allows a cycle through the colour temperature.
It is a start-stop dimming that means as soon as the dimming function becomes active the control
loop runs through the entire range. The dimming process ends either when the lower or upper end is
reached or when the push button is released again. When released, a "stop" telegram is sent.
The following table shows the available communication objects:
Number
Name/Object Function
Length
Usage
1
F1:
F1/2: –
Change colour temperature relative
4 Bit
Cycle through the colour temperature
3
F1:
F1/2: – Status for colour temperature
1 Byte
Receiving the status of the colour
temperature
Table 65: Communication objects – Colour temperature (Tunable White)
Presentation
Single-Button function
Two-Button function
The colour temperature is represented by a special symbol. The current status is evaluated by the
button and the current position is displayed with an arrow on the special symbol.
bar for colour temperature, status in “%”
It should be noted here: The value in percent corresponds to the “cold white” content.
bar for colour temperature, status in “%”
The limits for the colour temperature can be limited here via parameters.
The possible "minimum display range" is 2000 ... 3300 K [2700].
The possible "maximum display range" is 4000 ... 8000 K [6000].
The special symbol is shown below:
ETS-Text
Symbol
Comment
Symbol presentation
Table 66: Special symbol – Colour temperature (Tunable White)
