Technical Manual
Glass Push-button II Smart & Push-button Smart 86 [Series .02]
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Germany
Phone: +49-2263-880 • knx@mdt.de • www.mdt.de
59
59
Functional principle
With the two-button function, different values can be sent for the left and right buttons (for the short
and the long button). With the single-button function, only one value can be sent for both the short
and the long button. The data point type can be set separately for the short and the long button.
Presentation of the function
Since different datapoint types can be set for the short and the long button, either the function for the
long button or the function for the short button can be presented.
The "Status for display" object therefore only appears for the function that is being presented.
The following table shows the available communication objects:
Number
Name/Object Function
Length
Usage
0
F1 short:
F1/2 short: –
Switch, Percent value …
Sending the value for the short button.
DPT depending on the parameter setting
1
F1 short:
F1/2 short: –
Status for toggle
1 Bit
Receive the status for the short button.
Only with the "Toggle" function
1
F1 short:
F1/2 short: –
Status for display
Receive the status for the short button.
DPT depending on the parameter setting
No status possible for RGB
2
F1 long:
F1/2 long: –
Switch, Percent value …
Sending the value for the long button.
DPT depending on the parameter setting
3
F1 long:
F1/2 long: –
Status for toggle
1 Bit
Receive the status for the long button.
Only with the "Toggle" function
3
F1 long:
F1/2 long: –
Status for display
Receive the status for the long button.
DPT depending on the parameter setting.
No status possible for RGB
Table 42: Communication objects – Switch/send values short/long (with 2 objects)
