Technical Manual
Glass Push-button II Smart & Push-button Smart 86 [Series .02]
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Germany
Phone: +49-2263-880 • knx@mdt.de • www.mdt.de
58
58
The table below shows all available settings:
ETS-Text
Dynamic range
[Default value]
Comment
Action on short/long
keypress
▪ switch
▪ OFF
▪ ON
▪ toggle
▪ send value
▪ not active
Setting the function for the
short/long button.
- " Switch" only with
Two-button function.
- " Switch On/Off" only with
Single-button function.
Datapoint type
▪ 2 Bit DPT 2.001 Forcible control
▪ 1 Byte DPT 5.001 Percent value
(0…100%)
▪ 1 Byte DPT 5.005 Decimal factor
(0…255)
▪ 1 Byte DPT 17.001 Scene number
▪ 2 Byte DPT 7.600
Colour temperature (Kelvin)
▪ 2 Byte DPT 9.001 Temperature (°C)
▪ 2 Byte DPT 9.004 Brightness (Lux)
▪ 3 Byte DPT 232.600
RGB value 3x(0…255)
Only available for "send
values"
Sets the datapoint type for the
value to be sent.
Value left/right
button
any value according to set datapoint type
Only for two-button function.
Setting the values to be sent for
the two buttons.
Value
any value according to set datapoint type
Only for single-button
function.
Setting the value to be sent for
the button.
Behaviour on long
keypress
▪ do not send „short button“
▪ send „short button“
Setting whether the value for
the short button should also be
sent when the long button is
pressed.
Sending condition for
long keypress
▪ left and right button may send
▪ only left button may send
▪ only right button may send
Only for two-button function.
Setting the sending condition
for the long button.
Time for long
keypress
Basic setting
0,1 s – 30,0 s
Setting from when a long
keypress is detected.
Presentation of the
function
▪ display action of short button
▪ display action of long button
Setting which button is to be
shown as the status in the
display.
Table 41: Settings – Switch/Send values short/long (with 2 objects)
