Technical Manual
Glass Push-button II Smart & Push-button Smart 86 [Series .02]
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Germany
Phone: +49-2263-880 • knx@mdt.de • www.mdt.de
56
56
4.4.5.5 Presentation (Symbols)
Single-button function
Two-button function
The display of the function "Send values" depends on the selected data point type. Depending on the
selected data point type, 1-4 different symbols and their colour can be selected.
The following table provides an overview of the settings for the various datapoint types:
Datapoint type
Adjustable symbols
Comment
2 Bit Switch control, DPT 2.001
4 symbols can be set: 1 symbol
for each possible state
1 Byte Percent, DPT 5.001
Three icons can be set for the
ranges 0%, 1% - 90% and > 90%.
Therefore, the button evaluates
the information of the "Status for
display" object
Special presentation possible!
Additionally, it is possible to
display the status value below
the symbol.
1 Byte Decimal factor,
DPT 5.005
3 symbols can be set for the
ranges 0, 1-229 and 230-255.
Therefore, the button evaluates
the information of the "Status for
display" object
Special presentation possible!
Additionally, it is possible to
display the status value below
the symbol.
1 Byte Scene Number,
DPT 17.001
1 fixed symbol can be set
2 Byte Colour temperature
(Kelvin), DPT 7.600
1 fixed symbol can be set
2 Byte Temperature, DPT 9.001
1 fixed symbol can be set
Special presentation possible!
2 Byte Brightness, DPT 9.004
1 fixed symbol can be set
3 Byte RGB Wert, DPT 232.600
1 fixed symbol can be set
Table 39: Presentation (Symbols) – Send values
Special presentation
For certain datapoint types, a special presentation (see table above) is possible. In this presentation,
the status is shown on a larger scale on the display.
The following presentations are possible:
ETS-Text
Dynamic range
[Default value]
Comment
Special presentation
▪ bar symbol
▪ bar symbol with fan
▪ value as text (0-100%)
▪ value as text (0-255)
Only for DPT 5.001 and DPT 5.005.
If "bar symbol" and "bar symbol with
fan" are selected, the corresponding
symbol is presented, and the bar is
filled depending on the current
status.
If "value as text" is selected, the text
is shown large on the display.
Special presentation
▪ value as symbol + “°C”
▪ value as symbol without
unit
▪ value as symbol + “K”
Only for DPT 9.001.
With the settings "value as symbol",
the text is shown large on the
display.
Table 40: Special presentation – Send values
