Technical Manual
Glass Push-button II Smart & Push-button Smart 86 [Series .02]
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Germany
Phone: +49-2263-880 • knx@mdt.de • www.mdt.de
37
37
4.3.4 Slap / Cleaning function
The function is triggered by touching/pressing 3 or more buttons simultaneously.
The following picture shows the available settings:
Figure 16: Settings – Slap / Cleaning function
The following table shows the available settings:
ETS-Text
Dynamic range
[Default value]
Comment
Function
▪ Cleaning not active, Slap active
▪ Cleaning = long button,
Slap = short button
▪ Cleaning = short button
Slap = long button
Activation of the Slap / Cleaning
function and setting if activation
via short or long keystroke
Function: Slap / Cleaning = long / short button
Slap function for
short/long keypress
▪ OFF
▪ ON
▪ toggle
▪ send value
▪ not active
Setting the slap function.
Short/long button depending on
the selected concept.
Datapoint type
▪ 2 Bit DPT 2.001 Switch Control
▪ 1 Byte DPT 5.001 Percent
(0…100%)
▪ 1 Byte DPT 5.005
Decimal factor (0…255)
▪ 1 Byte DPT 17.001 Scene number
▪ 2 Byte DPT 7.600
Colour Temperature (Kelvin)
▪ 2 Byte DPT 9.001 Temperature (°C)
▪ 2 Byte DPT 9.004 Brightness (Lux)
▪ 3 Byte DPT 232.600
RGB Value 3x(0…255)
If selecting “Send values”:
Setting the data point type of
the value to be sent.
Depending on the selected
DPT, a parameter for the
corresponding value to be sent
is displayed.
Time for long
keypress
not active
0,1 s – 30,0 s
Setting an individual time from
when a long keystroke is
detected.
Display behaviour of
LEDs
any colour
Display behaviour of the LEDs
when the slap function is active.
Lock object
▪ not active
▪ active
Activation of the lock object for
the slap function.
