8
Wireless Connection
Your subwoofer includes a wireless transmitter that pairs with the wireless receiver built into the electronics of the
subwoofer. This wireless transmitter is completely optional, but offers a convenient way to send a signal to your
subwoofer when running a subwoofer cable is not a desirable option. The included transmitter can be powered
via an available USB port or with the included power adapter. The transmitter should be paired to the subwoofer
at the factory, but the built-in wireless receiver is powered off by default. See the controls section of the manual for
instructions on how to enable the wireless feature.
Simultaneous Connections
MartinLogan subwoofers can utilize multiple input methods simultaneously. This can be helpful in certain
installations, but the need to use simultaneous connections is rare, so this likely will not apply to your system. It is
not recommended to use both wireless and wired connections simultaneously.
LFE (or for devices with built-in bass management)
Single Wire Connection (or for devices without built-in bass management)
Stereo Connection
Trigger Input
12V DC
Right
Sub
Out
Line
Input
ARC Input
Power Mode
Power
Status
100-120V ,FUSE T8.0A H/250V
220-240V ,FUSE T6.3A H/250V
100-120VAC
220-240VAC
Speaker Level Input
Balanced
XLR Input
LFE In
Wireless
Audio
Left In+ – Right In+ –
10
Pair
On Auto
Status
LFE Left
Demo
Tone
Sweep
Control
Sweep
Status
Contains FCC ID: QOQ-GM220P
Contains IC: 5123A-GM220P
CAN ICES-003(B)/NMB-003(B)
TU VRh ei nla nd
Scan to download
Subwoofer Control App
Contains FCC ID: NKR-SWA12
Contains IC: 4441A-SWA12
Trigger
100-120V /220-240V
50-60Hz 500W
*If your device has multiple
subwoofer outputs, only connect ONE
Wireless Transmitter
Press Pair button
Power
Connect to USB Power
or included adapter
Sub1/LFE/Sub Out
Wireless Transmitter
Press Pair button
Power
Connect to USB Power
or included adapter
Left + Right Pre-Out
*If your device has multiple
subwoofer outputs, only connect ONE
Wireless Transmitter
Press Pair button
Power
Connect to USB Power
or included adapter
Sub Out
Speaker Level Input
Some electronics do not have dedicated subwoofer outputs and some enthusiasts like to connect their subwoofers
with a speaker level connection so that the subwoofer picks up the sonic signature of their chosen amplifier. To
that end, this subwoofer is also equipped with speaker level inputs, ready to accept a direct connection to your
amplifier using your preferred speaker cable. Banana plugs are required (not included) to use this input, as they
provide for a clean installation free from stray wires. This connection method presents no load to your amplifier,
and is safe for use even with balanced amplifiers.
