6 Martin
®
Exterior AC-Feeder and Exterior DC-Feeder Safety, Installation and User Manual
To connect an Exterior AC-Feeder to AC mains power – or to connect Exterior AC-Feeder
devices to AC mains power in a chain that takes power from one source – use minimum
18 AWG or 0.75 mm
2
conductor size power input cable that is suitable for the current draw,
environment and application. In the USA and Canada the cables must be UL/CSA-
recognized, hard usage, type SJTW, SJOOW or better. In the EU the cables must be type
H05RN-F, H07RN-F or better.
If you connect Exterior AC-Feeder devices to AC mains power in a chain that takes power
from one source, respect the following limits:
• When operating at 100-120 V~ do not link more than eight (8) fully loaded AC-Feeders in
total in a chain.
• When operating at 200-240 V~ or 277 V~ do not link more than sixteen (16) fully loaded
AC-Feeders in total in a chain.
If you connect Exterior DC-Feeder devices to each other in a daisy-chain that takes DC
power from one source, respect the following limit:
• Do not link more than sixteen (16) DC-Feeders in total in a chain.
Keep the supplied cable gland caps and connector caps installed on unused cable glands
and connectors at all times to maintain a seal against humidity and dirt.
Protection from burns and fire
Do not operate an Exterior AC-Feeder or Exterior DC-Feeder if the maximum ambient
temperature (T
a
max.) exceeds 55° C (131° F)
Protection from injury
Fasten the product securely to a fixed surface or structure when in use. The product is not
portable when installed.
Ensure that any supporting structure and/or hardware used can hold at least four (4) times
– or more if required by local regulations – the weight of all the devices and other items that
they support.
Use rigging hardware and fasteners that are in perfect condition, approved for the weight
that they will support, and suitable for their application and the installation environment. Do
not use safety cables as the primary means of support.
If you install an Exterior AC-Feeder or Exterior DC-Feeder on a truss or similar tubular
structure using a rigging clamp in a location where it may cause injury or damage if it falls,
install as directed in this manual a secondary attachment such as a safety cable that will
hold the product if a primary attachment fails. The secondary attachment must be approved
by an official body such as TÜV as a safety attachment for the weight that it secures, must
comply with EN 62368-2-17 Section 8.7 and must be capable of bearing a static suspended
load that is four (4) times – or more if required by local regulations – the weight of the
product and all installed accessories.
Check that all external covers and rigging hardware are securely fastened.
Block access below the work area and work from a stable platform whenever installing,
servicing or moving an overhead product.
Do not operate a product with missing or damaged covers.
In the event of an operating problem, stop using the product immediately and disconnect it
from power. Do not attempt to use a product that is obviously damaged.
Do not modify the product in any way not described in this manual. Install genuine Martin
parts only.
Refer any service operation not described in this manual to Martin Service or one of its
authorized agents.
