To edit the low pass filter
1. Press the appropriate output button 1 to 4 until the
button goes blue and the channel menu appears. For
details, see Output channels (page 25).
2. Rotate PM1 until LPF is shown top right and press
PM1 to select.
3. To change the frequency in 100Hz steps, rotate PM2.
To change the frequency in 1Hz steps, rotate PM3.
4. To change the slope, rotate PM1 so that Slope
appears on the bottom line of the screen. Then rotate
PM2 to select the slope. For a list of the slopes
available, see the table in the section
High pass filter
(page 28).
5. When you've finished editing, press PM2 to return to
the menu. To see what you can do next, see Output
channels (page 25) step 5.
Enable output EQ
This allows you to bypass the entire eight band output
EQ. You can use this to quickly compare the sound with
and without the output EQ. It doesn't change any of the
individual EQ parameters. For details of the eight band
output EQ, see Eight band output EQ (page 29).
To switch the output EQ on or off
1. Press the appropriate output button 1 to 4 until the
button goes blue and the channel menu appears. For
details, see Output channels (page 25).
2. Switching input and output EQ on and off is almost
identical, so use the instruction in Enable input EQ
(page 23) starting at step 2.
Eight band output EQ
There are eight bands of parametric EQ (PEQ) available
on each output channel. Each band is identical and you
can edit the type, frequency, gain, Q and slope.
You can use output EQ to adjust the response of a
particular loudspeaker or transducer and to correct for
room anomalies in multi-room setups.
In addition to output EQ, the DX0.4 has ten bands of input
EQ. For details, see
Ten band input EQ (page 23).
To change the eight band output EQ
1. Press the appropriate output button 1 to 4 until the
button goes blue and the channel menu appears. For
details, see Output channels (page 25).
2. If EQ is currently off, switch it on, as explained in
Enable output EQ (page 29).
You can only switch on EQ bands if
EQ is on.
3. Setting up input and output EQ is almost identical, so
use the instructions in Ten band input EQ (page 23)
starting at step 3.
DX0.4 User Guide
29
