Q218 specification
Type High-performance, dual 18" driver
subwoofer
Frequency
response
1
38 Hz – 100 Hz ± 3 dB, –10 dB @ 31 Hz
Driver 2 x 18” (460 mm) with 4” (100 mm) long
excursion voice coil, ferrite motor system
Rated power
2
1600 W AES, 6400 W peak
Recommended
electronics
DX0.4, DX0.6 or DX4.0 system processor
and VIA amplifier, or iKON amplifier-
processor
Sensitivity
3
104 dB
Maximum SPL
2,3
136dB continuous, 142dB peak,
148dBpeak with crest factor 4
Nominal
impedance
4 ohm
Dispersion Omnidirectional
Crossover Not applicable
Enclosure Durable plywood
Finish Black textured paint
Protective grille Black perforated steel grille with scrim cloth
backing
Connectors 3 x NL4 connectors: 2 at bottom rear (input
and link A), 1 at top rear (link B)
Pin connections
(input)
1+/1–
Pin connections
(link A)
1+/1–: Connected from input 1+/1–
2+/2–: Connected from input 2+/2–
Pin connections
(link B)
1+/1–: Connected from input 2+/2–
2+/2–: Not used
Fittings 24 x M10 inserts: 4 on top, 4 on bottom, 6 on
left, 6 on right, 4 on rear
16 x M8 inserts on rear for optional castors
4 x bar handles with recycled ABS pockets: 2
on top, 2 on bottom
M20 top-mounted thread plate for pole
mounting
4 x skids on base: for standing vertically
4 x skids on right side, 4 x recesses on left
side: for stacking horizontally
IP rating None
Dimensions (W) 536 mm x (H) 1206 mm x (D) 690 mm
(W) 21.1 in x (H) 47.5 in x (D) 27.2 in
Weight 82.5 kg (181.9 lbs)
Accessories
(optional)
Set of four castors WHEELKIT
M10 eye bolts HTKCT06
Wind-up telescopic pole ASF20071
Transit cover
1
On-axis in open space (4 pi) with full-range preset.
2
Tested for 2 hours with band-limited pink noise as specified in
AES2-1984 (r2003). Peak power defined as 6 dB above AES power.
3
In half space (2 pi) at 1m with 1 watt input.
BlacklineQ User Guide
27
