Q210 specification
Type Slimline, dual 10" driver subwoofer
Frequency
response
1
49 Hz – 100 Hz ± 3 dB, –10 dB @ 41 Hz
Driver 10” (250 mm) with 2” (50 mm) long
excursion voice coil, ferrite motor system
Rated power
2
400 W AES, 1600 W peak
Recommended
electronics
DX0.4, DX0.6 or DX4.0 system processor
and VIA amplifier, or iKON amplifier-
processor
Sensitivity
3
101 dB
Maximum SPL
2,3
127dB continuous, 133dB peak,
139dBpeak with crest factor 4
Nominal
impedance
4 ohm
Dispersion Omnidirectional
Crossover Not applicable
Enclosure Durable plywood
Finish Black or white textured paint
Protective grille Black or white perforated steel grille with
scrim cloth backing
Connectors 3 x NL4 connectors: 2 at bottom rear (input
and link A), 1 at top rear (link B)
Pin connections
(input)
1+/1–
Pin connections
(link A)
1+/1–: Connected from input 1+/1–
2+/2–: Connected from input 2+/2–
Pin connections
(link B)
1+/1–: Connected from input 2+/2–
2+/2–: Not used
Fittings 16 x M8 inserts: 2 on top, 2 on bottom, 4 on
left, 4 on right, 4 on rear
2 x bar handles with recycled ABS pockets,
1 at rear top, 1 at rear bottom
M20 top-mounted thread plate for pole
mounting
4 x skids on base
4 x skids on right side, 4 x recesses on left
side: for stacking horizontally
IP rating None
Dimensions (W) 296 mm x (H) 724 mm x (D) 462 mm
(W) 11.7 in x (H) 28.5 in x (D) 18.2 in
Weight 22.4 kg (49.4 lbs)
Accessories
(optional)
M8 eye bolt HTKCT05
Wind-up telescopic pole ASF20071
Transit cover
1
On-axis in open space (4 pi) with full-range preset.
2
Tested for 2 hours with band-limited pink noise as specified in
AES2-1984 (r2003). Peak power defined as 6 dB above AES power.
3
In half space (2 pi) at 1m with 1 watt input.
Q118 specification
Type Compact, high-performance 18" subwoofer
Frequency
response
1
38 Hz – 100 Hz ± 3 dB, –10 dB @ 31 Hz
Driver 18” (460 mm) with 4” (100 mm) long
excursion voice coil, ferrite motor system
Rated power
2
800 W AES, 3200 W peak
Recommended
electronics
DX0.4, DX0.6 or DX4.0 system processor
and VIA amplifier, or iKON amplifier-
processor
Sensitivity
3
101 dB
Maximum SPL
2,3
130dB continuous, 136dB peak,
142dBpeak with crest factor 4
Nominal
impedance
8 ohm
Dispersion Omnidirectional
Crossover Not applicable
Enclosure Durable plywood
Finish Black textured paint
Protective grille Black perforated steel grille with scrim cloth
backing
Connectors 3 x NL4 connectors: 2 at bottom rear (input
and link A), 1 at top rear (link B)
Pin connections
(input)
1+/1–
Pin connections
(link A)
1+/1–: Connected from input 1+/1–
2+/2–: Connected from input 2+/2–
Pin connections
(link B)
1+/1–: Connected from input 2+/2–
2+/2–: Not used
Fittings 16 x M10 inserts: 3 on top, 3 on bottom, 3
on left, 3 on right, 4 on rear
16 x M8 inserts on rear for optional castors
2 x bar handles with recycled ABS pockets,
1 on each side
M20 top-mounted thread plate for pole
mounting
4 x skids on base, 4 x recesses on top: for
stacking vertically
IP rating None
Dimensions (W) 530 mm x (H) 606 mm x (D) 690 mm
(W) 20.9 in x (H) 23.9 in x (D) 27.2 in
Weight 45.5 kg (100.3 lbs)
Accessories
(optional)
Set of four castors WHEELKIT
M10 eye bolts HTKCT06
Wind-up telescopic pole ASF20071
Transit cover
1
On-axis in open space (4 pi) with full-range preset.
2
Tested for 2 hours with band-limited pink noise as specified in
AES2-1984 (r2003). Peak power defined as 6 dB above AES power.
3
In half space (2 pi) at 1m with 1 watt input.
BlacklineQ User Guide
26
