4
www.marshall-usa.com
BACK PANEL FEATURES
2 3 4 5 6
1. Barrel Power Connector
12V DC power input 5.5mm x 2.1mm push-on connector.
Plug the supplied DC power adapter here. (Center pin is +)
Important: Please connect only one type of power supply at a time to
this monitor.
2. 4-Pin Connector
4-pin XLR DC power input compatible with typical broadcast television camera 12-volt power
supplies. Caution: Some 4-pin power supplies provide 24 volts. These are NOT compatible with this
monitor. Please check the label on the power supply before connecting.
1
7 8 9 10 11 12
13
