www.marshall-usa.com
5 6
CV730-ND3/ND3W
www.marshall-usa.com
2.1.3 Bottom
NO. Item Function Descriptions
1. Mute cooling fan
The cooling fan automatically controls its rotation speed and
performs cooling in cope with the operation temperature of the
machine
2.
Tripod lock hole The camera is mounted on a (specification) 1/ 4”-20 UNC tripod
3. Rotatable foot pad
When using the metal plates of accessories, remove 4 pieces of
rotatable food pads on the bottom by rotating counterclockwise,
and then install the mental plates
Status Power Standby
Startup in progress
(initialization)
Green light Orange light
In use Green light No indicator
In standby mode No indicator Orange light
2.2 Tally Lamp Function Description
The Tally light function may be enabled through the RS232 command.
Please refer to CV730-ND3/ND3W RS-232 command set document
2.3 Description of LED indicator
Chapter 3: Instruction for installation
3.1 Camera Size
3.1.1 Camera Front View and Side View
• Length x Width x Height: 233 x 188 x 189 mm
• Weight: 3.0 Kg (without mental plates)
3.1.1.1 Bottom of Camera
The camera can be mounted on a 1/ 4”-20 UNC PTZ tripod deck by using the lock
holes on the bottom for the tripod
1
17
1
18
1
19
