Marantz Horizon
Technical Specifications
Amplifier
Total Amplifier Power (FTC) 310 W (FTC Power Output Rating)
Total Amplifier Power (Peak) 745W (This rating was not tested
under the FTC standard)
Total Amplifier Power (Peak, Raw Amplifier Power) 1160 W (This rating was not tested
under the FTC standard)
Amplifier Toplogy Marantz Rise GaN FET
Loudspeaker Array
Bass 1× 6.5" Marantz Gravity
Wideband 3× 2"
High Frequency 2× 1"
Performance
Frequency Response 30Hz to 20kHz (+/-3dB), 22Hz (-10dB)
Maximum SPL 104dB (1M)
Peak SPL 114.5dB (1M)
Audio Connectivity
Analog 1 pr. RCA L/R
Digital 1 ea. TOSLINK Optical
USB 1 ea. USB-C (Mass Storage)
HDMI 1 ea. eARC / ARC
Audio Format Support
Decoding Dolby Atmos, Dolby TrueHD, DSD
Dolby Digital+, Dolby Digital, LPCM
Max PCM Sample Rate / Bit Depth Stereo: 192kHz / 24 bit
Multi-Channel: 192kHz / 24 bit (7.1 Channel)
Max DSD Data Rate 5.6 MHz (DSD ×2)
Stereo File Formats (HEOS network share or USB) WMA: up to and including 192 kbps
AAC & MP3: up to and including 320 kbps
WAV, ALAC, FLAC: up to and including
24-bit/192kHz
DSD: 2.8 MHz, 5.6MHz
Streaming Technologies
Bluetooth BT 5.4
AirPlay AirPlay 2
Spotify Spotify Connect
Music Services and Sources
Music Services Supported Pandora, Spotify, TuneIn, SiriusXM,
(HEOS, subject to change Amazon Music, TIDAL, iHeartRadio,
and local availability) Deezer, Deezer HiFi, Mood:Mix,
Sony Hi-Res, AWA, QPlay, SoundCloud.
Music stored on mobile device Yes (iOS, Android, or Kindle Fire)
NAS (Network Attached Storage) Network share, UPnP
USB Storage Device Playback Yes (FAT32, NTFS formatted drives)
Networking & Control
Wired Connectivity Ethernet
Wireless Connectivity Dual band, 802.11 a/b/g/n/ac/ax
Control System Compatibility via TCP/IP Crestron, Control4, AMX
HEOS App iOS, Android, Kindle Fire
General
Product Color Moon Ray, Midnight Sky, Marantz Champagne
Included Certificate of Authenticity, QSG,
Power Cable, HDMI Cable
User Interface Volume up/down, Play / Pause, Multi colored
LED status indicator, Connect button (rear),
Bluetooth button (rear)
Dimensions (H × W × D) Inches 14.33 × 8.27 × 15.26
Dimensions (H × W × D) mm 364 × 210 × 387.5
Weight (lbs) 27.5
Weight (kg) 12.5
Design and specifications are subject to change by Marantz without notice.
www.marantz.com
