11
ENGLISH
Crimping operations
1. Retract the nibs by pressing the release knob.
2. Insert the connector and center it between the nibs.
3. Activate the trigger and advance the nibs then, the
connector is held between the nibs.
4. Insert the conductor into the connector.
5. Press the trigger until the compression is
completed. A click will be heard when compression
is completed.
6. Keep pressing the trigger. The ram automatically
retracts to the lower end. (Auto retract mode)
7. Remove the conductor from the tool.
WRONG RIGHT
Attaching the Shoulder belt
Optional accessory
The shoulder belt can be attached to the hanging rings
of the tool to carry the tool.
WARNING:
• Always remove the shoulder belt from the tool
when working with the tool. Failure to do so may
cause a loss of balance and result in an accident.
• Use only the shoulder belt designated for this
tool. Make sure that the shoulder belt is securely
attached to the tool when carrying the tool.
• When using the shoulder belt, carefully inspect
the shoulder belt and the hanging rings for
damage, cracks, or deformation. If there is any
damage, stop using the shoulder belt and ask Makita
Authorized Service Center for repair.
Maintenance/Inspection
• Daily maintenance is required to ensure that the tool is
kept in good condition.
• Do not store the tool in a humid environment to maintain
smooth movement of parts and to prevent rust.
• If the tool is damaged by normal operation at over
10,000 times, it is the end of its life.
Do not use the tool again even after replacement of the
damaged part.
• When a resin part becomes dirty, wipe away with a
soapy cloth.
• When the battery pack is stored alone, be sure to put
the accessory terminal cover on the terminal to prevent
short circuit.
• The tool performance may deteriorate due to
degradation of its parts or hydraulic oil.
Have your tool maintained every two years to use it to
the end of its life (with charge). For further information,
please contact an authorized service facility.
Declarations of Conformity
For European countries only
The Declarations of conformity are included in Annex A to this instruction manual.
