Item Description
Video Signal Status
Shows the video input signal information parsed by the device, including: Signal status(Shown as Locked, Unsupported, Not Present.),
Resolution, Aspect ratio, Total scan size, Active area offset, Color format, Quantization range, Saturation range, and etc.
If parameters changed in Timing tab, the related data would be changed accordingly.
Audio Signal Status
Shows the audio signal status parsed by the device, including audio sampling frequency, bit-depth and sampling format, multi-channel
audio, Channel status data, and etc.
Input Specific Status
Shows the input Specific Status.
When a HDMI signal is connected, shows Signal Status, Mode, HDCP encrypted, Color depth(The common ones are: 8 Bits, 10 Bits and
12 Bits.), Pixel encoding, VIC, IT content, 3D format, timing and etc.
■
HDCP encrypted Shows whether the signal source is HDCP encrypted, “Yes” or “No”. In accordance with the related laws and
regulations, the USB capture device doesn't capture HDCP encrypted signals.
When a VGA signal is connected, it shows Signal Status, Sync type, Frame rate, Scanning format, VS width, Total scan lines, timing, and
etc.
■
When Composite or YC is connected, it shows the TV standard of the current input signal.
■
When an SDI signal is connected, it shows Signal Status, Type, Scanning format, Color depth, Sampling struct, and etc.
■
