Figure1. Set Source Video parameters in the Web UI

Figure2. Monitor Pro Convert devices using NDI Studio Monitor

Setting Source Video

NDI

NDI is a standard developed by NewTek to transport IP video over a LAN with high-quality and low latency. Note that you need to click Apply at the bottom-right

corner of the page to save changes.

Group name shows the group that receives NDI streams sent by your

converter.

■

The group name is non case-sensitive, and should contain A to Z, a to z,

0 to 9 and special characters like _-. The group name entry can contain

comma-separated values, allowing your converter to send to all the

groups listed here.

■

The default group is public group.

■

To make a private NDI group, refer to Creating a Private Group.

■

Source name shows the NDI source name used for your converter.

■

By default, the source name is #%board-id% (%serial-no%). when you

monitor Pro Convert devices using NDI Studio Monitor, the NDI stream

name is displayed as on the left in Figure2.

■

You can change the board-id via the rotary switch on your unit.

■

serial-no indicates the unit's serial number, as per the barcode label.

■

%board-id% and %serial-no% are the only supported variables.

■

You can change the Source Name to a string with maximum of 30

characters, containing A to Z, a to z, 0 to 9, spaces and special

characters like _-#()%.

■

If no text is entered for the Source Name, it will take the default value

■
