Setting INPUT EDID

Any of the following actions can be performed on the input EDID of the device.

Add audio

■

Force the source device to output audio.

■

If users connect a monitor which doesn’t support audio to the loop-

through output, the source device will decide not to output audio. As a

result, the Pro Convert will not get any audio input. If Add Audio is

enabled, the Pro Convert will communicate with the video source device,

forcing it to output audio.

■

Limited pixel clock

■

If enabled, when the pixel resolution of the loop-through device is

beyond the capability of the Pro Convert, a lower pixel resolution will be

used in order to avoid the output producing a blank screen.

■

Default: Click Default to reset the current EDID to default values.

■

Import: Click and select an EDID file to import a local EDID file.

■

Export: Click and set the file name to export the current EDID as a .bin file.

■

31
