MACKIE MATRIX LIVE STREAMING MIXER SOFTWARE

35

Input Meters – On the bottom-lef of the screen are the input meters. The stereo input meters display the relative level

of each input channel. They should remain green with the occasional bump into the yellow zone. Turn down the volume

if the input meter remains consistently yellow. If the input is too high [overloading], a clip indicator at the top of the meter

will illuminate red. If clipping occurs, reduce the volume.

This only displays the input meter level. The input may be lowered by either () lowering the source

of the input and/or (2) lowering the input fader level (located on the main mixing screen).

Ok friends, let’s swing on over to the upper-right side of the screen now!

X – Clicking on the “X” will close out the Control Mode window and return

you to the mixer view.

This is the only way to access the mixer view. The Control Mode screen

cannot be “moved out of the way” to make changes to the mixer view.

RTA – RTA is discussed in depth on page 40.

Expand/Contract – The Control Mode window may be scaled for a larger

(or smaller) look, how ’bout them apples?! In the lower-right corner

of the screen are several diagonal lines. These may be clicked (and held)

while moving the mouse down and out/right (screen expands) or up

and in/lef (screen shrinks).

Again, regardless of screen size, the Control Mode

screen cannot be “moved out of the way” to make

changes to the mixer view.

Output Meters – The output meters display the output signal level, presented in stereo L/R.

The meters should remain green with the occasional bump into the yellow zone.

If there is too much yellow (or any red clipping), lower the output gain (more below)

until it’s gone and check the input channels, as well.

Output Gain – Located to the lef of the output meters is the output gain control.

Use it to raise/lower the output gain by up to ±2 dB. This may be changed one of two ways:

() hovering inside of the output gain circle, then rotating the mouse wheel to change the

output gain; increments will be ± dB, or (2) lef (or right)-click (and hold) the mouse

inside of the output gain circle while also moving the mouse up (increases gain) or down

(decreases gain) by ±0.xx for even more detailed settings!
