11
Specifications
Rated output 30W + 30W (6Ω), 25W + 25W (8Ω, 4Ω)
Input sensitivity/input impedance 1.0V / 47kΩ
Frequency response 20Hz ~ 100kHz (within –3dB)
Total harmonic distortion rate 0.5% / or less (1kHz, 30W / 6Ω)
S/N ratio 75 dB or more (IHF-A weighted)
Input 1 phono line (MM / MC high / MC low supported) and 4 lines
Recording input/output 1 line for each of record output and monitor input
Separate input/output 1 line for each of pre output and main input
Output
Speaker output A and B (independent selection, both simultaneous
outputs available)
Circuit Driver: Mullard circuit, output: UL connection
Vacuum tube used 4 pieces of EL34, 4 pieces of ECC83, 3 pieces of ECC82
Accessories
· Remote control · Power cable
· Terminal protection cap · Owner's Manual
· Safety cautions · Coin-type battery (CR2025)
Power supply voltage AC 230V (50Hz)
Power consumption 195 W, 150 W (under no signal)
Max. external dimensions
400 x 196 x 310 mm (WxHxD) (terminals and knobs excluded from the
dimension)
Weight 20.0kg (main unit only)
* Specifications and appearance are subject to change without notice.
