SPECIFICATION SUBMITTAL Page
Job Name:
Job Number:
Model Numbers:
Caséta by Lutron Load Controls
369987l 5 2.24.23
1
Cannot be ganged.
2
Need to change load type to MLV. See www.casetawireless.com/change_phase
3
See bulb list at www.lutron.com/led
4
For PD-10NXD, a neutral connection is required for MLV loads, LED drivers, dimmable ballasts, and power modules (PHPM-PA, PHPM-3F, and GRX-TVI).
5
Compatible dimmable ballasts include Tu-Wire, Mark 10R, and PowerSenseR.
6
These loads are best operated using a forward-phase control. Consult https://www.casetawireless.com/support to ensure the appropriate phase for bulb
models used.
7
SSL7 compliant when in forward-phase.
8
Canadian packaged product.
9
Available in WH only.
Load Type and Capacity - Dimmers
Model Number Description Voltage Load Type
Minimum
Load
Maximum Load
Not Ganged End of Gang Middle of Gang
PD-10NXD
PD-10NXD-XX-C
8
Dimmer PRO
(neutral
connection
required for
certain load
types)
4
120 V~
Incandescent / Halogen
10 W with
neutral (25 W
without neutral)
1000 W 800 W 600 W
MLV Halogen 10 W 1000 VA 800 VA 600 VA
MLV LED See Application Note #559
LED (120 V~ Rated)
3
1 bulb
3
250 W 250 W 250 W
Hi-lume 1% 2-Wire LED
drivers
1 driver 13 drivers 13 drivers 13 drivers
Dimmable Ballasts
5
1 ballast 1000 VA 800 VA 600 VA
PHPM-PA / 3F and
GRX-TVI
4
1 interface 3 interfaces 3 interfaces 3 interfaces
PD-3PCL
1, 9
PD-3PCL-WH-C
1, 8, 9
Plug-In Lamp
Dimmer
120 V~
Incandescent / Halogen 10 W 300 W N/A N/A
LED (120 V~ Rated)
3
1 bulb
3
100 W N/A N/A
PD-5NE
PD-5NE-XX-C
8
Phase
Selectable
Dimmer
(neutral
connection
required)
120 V~
Incandescent / Halogen 10 W 500 W 400 W 300 W
LED (120 V~ Rated)
3, 6, 7
1 bulb
3
250 W 250 W 250 W
MLV Halogen
2, 6, 7
10 W 400 VA 400 VA 400 VA
ELV Halogen 10 W 500 W 400 W 300 W
Hi-lume 1% 2-Wire LED
drivers
6, 7
1 driver 20 drivers 20 drivers 20 drivers
Dimmable Ballasts
5, 6, 7
1 ballast 400 VA 400 VA 400 VA
PHPM-PA / 3F and
GRX-TVI
6, 7
1 interface 3 interfaces 3 interfaces 3 interfaces
ELV LED See Application Note #559
MLV LED
6, 7
See Application Note #559
PD-6WCL
PD-6WCL-XX-C
8
DVRF-6L
Dimmer 120 V~
Incandescent / Halogen 25 W 600 W 500 W 400 W
LED (120 V~ Rated)
3
1 bulb
3
150 W 150 W 150 W
5
