SPECIFICATION SUBMITTAL Page

Job Name:

Job Number:

Model Numbers:

Caséta by Lutron Load Controls

369987l 4 2.24.23

Load Type and Capacity - Switches and Fan Control

Model Number Description Voltage Load Type

Minimum

Load

Maximum Load

Not Ganged End of Gang Middle of Gang

PD-5WS-DV

Two-wire

switch

120 V~

Incandescent /

Halogen

25 W 600 W 450 W 350 W

277 V~

Incandescent /

Halogen

25 W 1350 W 110 0 W 800 W

120 V~ MLV 25 W 600 VA / 475 W 450 VA / 350 W 350 VA / 275 W

277 V~ MLV 25 W 1350 VA / 1075 W 1100 VA / 875 W 800 VA / 625 W

120 V~

General

Purpose Fan

0.4 A 3 A 3 A 3 A

120 / 277 V~ LED Use LUT-MLC

5 A 4 A 3 A

120 / 277 V~ Fluorescent Use LUT-MLC

5 A 4 A 3 A

120 V~ ELV Use LUT-MLC

600 W 450 W 350 W

277 V~ ELV Use LUT-MLC

1350 W 110 0 W 800 W

PD-5ANS

DVRF-5NS

Neutral-wire

switch

(neutral

connection

required)

120 V~

Incandescent /

Halogen

10 W 600 W 600 W 600 W

MLV 10 W 600 VA 600 VA 600 VA

Fan 0.1 A 3 A 3 A 3 A

LED 1 bulb 5 A 5 A 5 A

Fluorescent 1 ballast 5 A 5 A 5 A

ELV 10 W 600 W 600 W 600 W

PHPM-SW 1 interface 2 interfaces 2 interfaces 2 interfaces

PD-6ANS

PD-6ANS-XX-C

Neutral-wire

switch

(neutral

connection

required)

120 V~

Incandescent /

Halogen

10 W 720 W 720 W 600 W

MLV 10 W 720 VA 720 VA 600 VA

Fan 0.1 A 3.6 A 3.6 A 3.6 A

LED 1 bulb 6 A 6 A 5 A

Fluorescent 1 ballast 6 A 6 A 5 A

ELV 10 W 720 W 720 W 600 W

PHPM-SW 1 interface 3 interfaces 3 interfaces 3 interfaces

PD-FSQN

Fan speed

control

(neutral

connection

required)

120 V~

Single Ceiling

Fan (permanent

split-capacitor

motor)

0.1 A 1.5 A 1.5 A 1.5 A

No neutral wire required.

To ensure proper operation of the switch with LED, fluorescent, and ELV loads, a LUT-MLC (included) may be required, especially at lower wattages. If the

status LED on the switch is flashing or solid red in color, a LUT-MLC must be installed. To guarantee best performance, installing a LUT-MLC with these load

types regardless of wattage is recommended. Rarely, some load types may still flicker or glow in the off state even with the LUT-MLC installed, in which case

a different load may be required or more than one LUT-MLC is required.

See “Ganging and Derating” section.

Not for use with fans that have integrated fan speed and / or light control modules, DC motor fans, fans with remote controls, bathroom or kitchen exhaust

type fans.
