SPECIFICATION SUBMITTAL Page
Job Name:
Job Number:
Model Numbers:
Caséta by Lutron Load Controls
369987l 26 2.24.23
Wiring Diagrams - Dimmers (continued)
Multi-location Installation (load is controlled from 3 or more locations) (continued)
Option 2: With accessory switches
DVRF-6L and Smart Accessory Switches (DVRF-AS)
1, 2
¹ Up to ten (10) accessory switches may be connected to the dimmer. Total blue wire connection wire length may be up to 150 ft (45 m).
2
When using an accessory switch in a multi-location installation with a dimmer, the Black and Red wires of all devices are reversible.
Load
Red
Line /
Hot
Green
Blue
Ground
Neutral
120 V~
60 Hz
Green
Ground
Black
Black
Ground
Green
Red
Black
Accessory Switch Accessory Switch
DVRF-6L (Line Side)
Red
Dimmer
Accessory Switch
Ground
Green
Red
Black
Note: Main dimmer can go in any location.
DVRF-AS
DVRF-AS
DVRF-AS
DVRF-6L (Load Side)
DVRF-6L (In the Middle)
DVRF-6L
Load
Red
Line /
Hot
Green
Blue
Ground
Neutral
120 V~
60 Hz
Green
Ground
Black
Black
Ground
Green
Red
Black
Accessory Switch Dimmer
Red
Accessory Switch
Accessory Switch
Ground
Green
Red
Black
DVRF-AS
DVRF-AS
DVRF-6L
DVRF-AS
Load
Red
Line /
Hot
Green
Blue
Ground
Neutral
120 V~
60 Hz
Green
Ground
Black
Black
Ground
Green
Red
Black
Dimmer Accessory Switch
Red
Accessory Switch
Accessory Switch
Ground
Green
Red
Black
DVRF-AS
DVRF-6L
DVRF-AS
DVRF-AS
26
