DMX OPERATION

DMX OPERATION - Advanced Settings

BLUETOOTH

NOTE: The symbol - ! - on the display indicates that there

is no DMX signal.

1. Press the

push button to enter the main MENU.

2. Select DMX with the

knob and press the

push button to conrm selection.

3. Select the light mode between CCT / HSI / RGBW / FRGBW / PRESET with the

knob and press the

push button

to conrm selection.

4. Select the DMX channel, rotating the

knob to change DMX ADDRESS in ascending or descending order between

1 and 512. The number shown on the display

is the selected channel to communicate with the control desk.

1. See DMX PROTOCOL MANUAL to DMX channel specication.

1. Press the

push button to enter the main MENU.

2. Navigate through the main MENU with the

knob and press the

push button to conrm selection.

3. Rotate the

knob to select DMX ADVANCED, press the

push button to conrm selection.

4. Select one of the options among the DMX BIT, DMX SIGNAL LOSS and RDM ENABLE, press

push button to

conrm the selection.

DMX BIT:

Resolution of the DMX control. 8bit 1 channel per function and 16 bit 2 channels per function.

1. Select the DMX BIT item by pressing the

push button.

2. Rotate the

knob to choose between 8bit / 16bit, press the

push button to conrm the selected setting. See

DMX PROTOCOL MANUAL.

DMX SIGNAL LOSS:

This feature allows to choose the device’s behaviour in case of a DMX signal loss.

1. Select the LOSS DMX SIGNAL item with the

push button

2. Rotate the

knob to select the device’s behaviour between BLACK OUT /SETTINGS LAST / SETTINGS 1min,

press the

push button to conrm the setting.

Black out: The device switches off.

Settings Last: The values of the last selected setting are maintained over time until the device is switched off.

Settings 1min: The values of the last selected settings is maintained for one minute and then the device is switch

off.

RDM Enable: ON/OFF, enable/disable RDM Protocol

INV CCT: ON/FF: enable/disable reversal CCT console control

1. Press the

push button to enter the main MENU.

2. Navigate through the main MENU with the

knob and press the

push button to conrm selection.

3. Rotate the

knob to select BLE, press the

push button to conrm selection and to

enable/disable BLE App interface.

DMX Protocol

Introduction

The Actionpanel Full Color, the Superpanel 30 Full Color and the Superpanel 60 Full color can be used with 8 bit or 16

bit DMX control.

(See DMX OPERATION - advanced settings in the user’s manual).

When used in 8 bit mode the panels uses one channel for each function. DMX values for each channel are in
