- In current mode press the

push button to enter the main MENU.

- In the sub-menus press the

push button to conrm a selection.

- Rotate the

knob to navigate in the main MENU and sub-menus.

- Use the « INTENSITY »

knob to adjust the light intensity from 0 to 100%.

- Use the knobs

and

to adjust the light mode parameters.

- Display

CONTROL PANEL

MANUAL OPERATION

LIGHT MODES

1. Press the

push button to enter the main MENU.

2. Select MANUAL by pressing the

push button.

3. Select the light mode between CCT / HSI / RGBW / PRESET / EFFECT / SAVE PRESET with the

knob and press

the

push button to conrm selection.

4. See LIGHT MODES.

MODE

CCT

RGBW

HSI

PRESET

CCT/HUE

CT 2800K to 10000K

HUE 0º to 100º

GN/SAT/COLOR

« »

GN -1.00 to +1.00 -

Select function R/G/B/W/CT/GN Change values of the function

SAT 0 to 100% -

- Change Preset

INTENSITY

Light Intensity

from 0 to 100%

A. CCT MODE: Warm and cold white control mode. It allows you to adjust colour temperature (CCT), green/magenta

compensation (GN) and light intensity. This is the default setting.

B. HSI MODE: Colour composition mode. It allows you to adjust hue of colour (HUE), colour saturation (SAT) and

light intensity.

C. RGBW MODE: RGBW colour control mode allows to individually set the R, G, B, W, Color Temperature (CT), green/

magenta compensation (GN) values and to adjust light intensity

D. FRGBW MODE: Available only in DMX operation. Same as RGBW but with white color power unlimited. See DMX

PROTOCOL MANUAL.

E. PRESET MODE: Mode with 53 PRESET colors, 48 factory preset and 5 user-dened preset.

1. In MANUAL OPTIONS or DMX MODE menu select PRESET MODE.

2. Select the PRESET to be activated rotate the

button, conrm the selection by pressing the

push button.

3. Use the « INTENSITY »

knob to adjust the light intensity from 0 to 100%.

SAVING THE SET VALUES AS A PRESET

You can store up to 5 PRESETS.

1. In MANUAL select SAVE PRESET by pressing the

push button.

2. Save the set values in one of the available presets between USER PRESET 1 / 2 / 3 / 4 / 5 rotate the

knob to

select the PRESET number and press the

push button to conrm the selection. THE SET COLOR IS SAVED AS

PRESET.

"BUSY" indicates that in the user preset there are parameters memorized if you select it, the parameters is

replaced by the new ones. "EMPTY" indicates that the user preset is free.

ATTENTION: The light intensity level is adjustable from 0 - 50% if the

FAN is OFF. The value on the display ashes.
