26

DMX OPERATION - Advanced Settings

1. Press the

5

push button to enter the main MENU.

2. Navigate through the main MENU with the

5

knob and press the

5

push button to conrm selection.

3. Rotate the

5

knob to select DMX ADVANCED, press the

5

push button to conrm selection.

4. Select one of the options among the DMX BIT, DMX SIGNAL LOSS and RDM ENABLE press

5

push button to

conrm the selection.

DMX BIT:

Resolution of the DMX control. 8bit 1 channel per function and 16 bit 2 channels per function.

1. Select the DMX BIT item by pressing the

5

push button.

2. Rotate the

5

knob to choose between 8bit / 16bit, press the

5

push button to conrm the selected setting. See

DMX PROTOCOL MANUAL.

DMX SIGNAL LOSS:

This feature allows to choose the device’s behaviour in case of a DMX signal loss.

1. Select the LOSS DMX SIGNAL item with the

5

push button

2. Rotate the

5

knob to select the device’s behaviour between BLACK OUT /SETTINGS LAST / SETTINGS 1min,

press the

5

push button to conrm the setting.

Black out: The device switches off.

Settings Last: The values of the last selected setting are maintained over time until the device is switched off.

Settings 1min: The values of the last selected settings is maintained for one minute and then the device switch

off.

RDM Enable: ON/OFF, enable/disable RDM Protocol

INV CCT: ON/FF: enable/disable reversal CCT console control

RDM

Protocol Specication

COMMAND

Manufacturer ID

Device Identication

Model ID Model identication number

Dayled 650 mono color

Dayled 650 dual color

Dayled 1000 mono color

Superpanel 30 dual color soft

Dayled 2000 mono color

Superpanel 30 full color soft

Dayled 1000 dual color

Superpanel 30 dual color lens

Dayled 2000 dual color

Superpanel 30 full color lens

1

2

3

7

5

9

4

8

6

10

PID

0x0622

DESCRIPTION

Manufacturer identication number

(LUPO Lighting).

Superpanel 60 dual color soft

Superpanel 60 dual color lens

11

12

Superpanel 60 full color soft13
