20

Set the device to its factory defaults. Get: Check if

settings still in default state -> 1 if default

Retrieves software version string of main software

FACTORY DEFAULTS

SOFTWARE VERSION LABEL

0x0090

0x00C0

DMX mode

The identify ag (ashes the light)

Shows a description of a DMX-Mode, max 32 characters

DMX address

DMX PERSONALITY

IDENTIFY DEVICE

DMX PERSONALITY

DESCRIPTION

DMX START ADDRESS

0x00E0

0x1000

0x00E1

0x00F0

DMX512 Setup

Control

Manufacturer Commands

0: Off 1: On

0: 30 sec 1: 1 min 2: always on

0: black out 1: last settings on 2: last settings 1 min

0: 8 bit 1: 16 bit

0: 2800-10000 1: 3200-5600

FAN MODE

DISPLAY TIMEOUT

DMX SIGNAL LOST MODE

DMX BITS

CCT LIMIT

0x8001

0x8002

0x8003

0x8004

0x8005

0: linear 1: exponential 2: logarithmic

0: full speed 1: normal speed 2: high speed 3: low speed

LINEARIZATION

FILTER

0x8006

0x8007

0: 18 KHz 1: 25 KHz

0: not inverted 1: inverted

FREQUENCY

INV - CCT

0x8008

0x8009

1. Press the

2

push button to enter the main MENU.

2. Navigate through the MENU rotating the

2

button, select DEVICE SETTINGS, press the

2

push button to conrm

the selection.

3. Navigate through the MENU rotating the

2

button, select GENERAL, press the

2

push button to conrm the

selection.

4. Navigate through the FAN POWER / DISPLAY / FREQUENCY / FILTER / LINEARIZATION / CCT LIMIT functions,

rotating the

2

button to select the desired function and press the

2

push button to conrm the selection.

5. Within each function select the option to be activated and rotate the

2

button.

Fan Power: Fan operation ON / OFF.

When the fan is OFF the light intensity be adjustable between 0 and 50%.

Display: Time during which the display backlight stays on. 30sec / 1min / ALWAYS ON.

Frequency: Dimmer frequency 18 KHz - 25 KHz

Filter: It is the speed response of the system (smooth factor).

FULL SPEED / NORMAL SPEED / HIGH SPEED / LOW SPEED.

Linearization: Linearization is the compensation curve for the human eye's perception of the luminous

intensity emitted as a function of the required power. Required power = dimmer value on the display. LINEAR /

EXPONENTIAL / LOGARITHMIC.

Linear: No compensation, the intensity of the light is directly proportional to requested power.

Exponential: The light intensity increases from 0 to 100 exponentially.

Logarithmic: The light intensity increases from 0 to 100 logarithmically.

CCT Limit: CCT range 2800 - 6500 or 3200 - 5600

DEVICE SETTINGS
