12
XP800
Problem Possible causes Solution
6. The winch cannot be
weighed: the gear
motor runs, the
shaft runs, but the
gypsy is still.
6.1 The gypsy is not closed on the
clutch cones and slips under the
load effect, or for some reason
the closing wheel is at end stroke.
Check out all pieces in sequence.
6.2 The clutch cones or the gypsy
cones are deformed and the
clutch hubs are in contact and
prevent closure.
6.1 Check out clutch tightening. If necessary, measure the
parts and check out possible deformations. It is possible to
add some thickness to stem the problem. Then replace the
damaged parts.
6.2 Replace the clutch and/or the gypsy.
7. The shaft does
not run well, is not
aligned, and so is
the gypsy.
7.1 The gear motor shaft bent
because the winch was subjected
to an excessive load.
7.1 Check out that the procedures of use fall within the specifi-
cations of the winch. (SERVICE) Uninstall the winch and
replace the planetary gearbox. Take this opportunity to
replace worn parts, gaskets, screws, tabs.
8 TECHNICAL DATA
Motor Power
500W
Up to Vessel Length (mt. / ft)
11 / 36
Supply (power & command)
12V
Maximum linear Load/Pull (Kg / lb)
160 / 353
Max Lift Working Load (Kg / lb)
95 / 210
Amps Work Load (A)
35
Max Line Speed (mt./min. / ft/min.)
21 / 69
Line Speed (mt./min. / ft/min.)
17 / 56
Net weight Low Profile (Kg / lb)
10 kg
Gipsy 6mm 7mm 8mm
Chain supported
6mm 6mm 3/16” 7mm 7mm 1/4” 1/4” 8mm 8mm 5/16” 5/16”
ISO DIN 766 BBB ISO DIN 766 G4 BBB ISO DIN 766 G4 BBB
Rope supported
10-12-1/2” mm 3-strand
14mm 3-strand rope
10-12-1/2” mm 3-strand 14mm
3-strand rope
10-12-1/2” mm 3-strand 14mm
3-strand rope
