11
www.lofrans.com
UK
1. By turning anticlockwise, remove the hand-wheel of the gypsy through the manoeuvre handle.
2. Remove the 2 M10 screws from the side of the base that connect the stripper and remove it.
3. Slip off from the shaft the upper clutch cone, the gipsy, and the lower clutch cone.
4. Wash with running water. DO NOT USE WATER UNDER PRESSURE.
5. Check that there is no evidence of corrosion or mechanical stresses.
6. Reassemble by proceeding in the reverse order, remembering to lubricate threads and all moving parts with grease.
6.2 Gipsy maintenance/replacement
Problem Possible causes Solution
1. The anchor
windlass does not
work when a control
is operated
1.1 Protection switch in OFF
position
1.2 Lack of voltage in the system
1.3 Failure of the control box
1.4 Failure of the control
1.5 Failure of the electric motor
1.1 Check the protection switch and set it in the ON position
1.2 Check the charge status of the battery, check connections
1.3 Check and possibly replace the control box
1.4 Check and possibly replace the control
1.5 Measure the electric motor voltage; if it is OK, check the brushes
and clean them. If it does not work, replace the electric motor
2. The chain jams
frequently
2.1 The chain locker is not deep
enough with respect to the
quantity of chain chosen
2.2 The chain is not suitable for
the gipsy
2.3 The chain is not calibrated
2.1 Position the anchor windlass in the deepest point of the chain
locker or reduce the quantity of chain
2.2 Change the gipsy
2.3 Check the chain: if it does not meet the tolerances, it must be
replaced
7 TROUBLESHOOTING
