2. Toggle/Self-Locking:

- Press one button on the remote control for one time to turn ON

thecorresponding channel of the receiver.

- Press again the same button to turn OFF the receiver’s channel.

3. Latched/Interlocking outputs:

- Press one button on the remote control for one time to turn ON the

corresponding channel of the receiver.

- Press another button on the remote control to turn OFF the receiver’s

output.

Figure A Figure B

Setting of Working Modes:

1. Momentary Mode:

Pressing the learning key button on the receiver board once (g.A) and the

LED indicator on receiver board will signaling simultaneously. Then press any

of the remote control button (g.B) as a result the LED on the control board

ashes 3 times in succession meaning that the setting of the Momentary Mode

is successfully. The corresponding output is ON by pressing a remote control

button and only when you release the remote control button the output turns off.

If the remote button key is not released, the relay is always on.

2. Toggle Mode (Self-locking):

Pressing the learning key button on the receiver board twice (g.A) and the

LED indicator on receiver board will signaling simultaneously. Then press any

of the remote control button (g.B) as a result the LED on the control board

ashes 3 times in succession meaning that the setting of the Toggle Mode is

successfully. All outputs work as self-locking. Pressing a remote control button

once, the relay is on and the corresponding output is activated. By pressing the

same button again, the output turns off.
